DS-2CE56D7T-IT3Z HD-TVI TURBO HD 3.0 Camera: Hikvision (ceiling, 1080p, 2.8-12 mm motozoom, 0.01 lx, IR up to 40m)

  • Description
  • Reviews (0)


HD-TVI TURBO HD camera DS-2CE56D7T-IT3Z has been designed for use in CCTV systems based on HD-TVI DVRs. The camera provides 1080p video. With high sensitivity (0.01 lx) and built-in IR illuminator with range up to 40 m, the camera ensures high quality image in low light or even no-light conditions. The camera can be used in various environments, thanks to IP66 rating and very wide operation temperature range.
High Definition Transport Video Interface (HD-TVI) is a revolutionary technology that allows users to send uncompressed, high-resolution video (up to 1080p) over coaxial or twisted-pair cables (using dedicated baluns). The transmitted video signal is in analog form, with bandwidth much greater than in the case of CVBS (SD). As the signal is not compressed, the picture is more natural during live viewing. There is no delay and the configuration of such a system is easier compared to IP CCTV solutions.
The access to the OSD menu of the camera is possible via the video cable. The control of the menu is performed with the use of the compatible DVR connected with the camera. All control functions of the menu are accessible after selecting PTZ control option in the DVR.
The application of varifocal motorized lens allows for remote adjustment of the focal length and the field of view of the camera. Such adjustments can be stored in the DVR as presets and recalled as responses to alarm situations.
The OSD menu includes Wide Dynamic Range (WDR) function that can be switched on/off depending on the environment. By default, WDR function is switched off.
Mechanical IR-cut filter ensures perfect color rendition in daylight and full sensitivity with IR lighting.
