DS-2DE5220I-AE 2MP IP PTZ Camera Hikvision (20x optical zoom 4.7-94mm, IR up to 150m, PoE+)

Key features

• high-speed dome PTZ camera,
• max. resolution 2 MP / 1920×1080 @ 25 fps),
• focal length f = 4.7…94 mm (optical zoom 20x),
• image processing functions: 3D DNR, D WDR, BLC, HLC,
• 8 patrols, each with up to 32 presets,
• audio in/out: 1/1,
• alarm in/out: 2/1,
• two video streams,
• mechanically switching IR filter,
• intelligent image analysis (intrusion detection, virtual line crossing, motion detection, audio exception),
• microSD card slot for a microSD/microSDHC/microSDXC card up to128 GB,
• support for IE, Firefox, Safari, iPhone, Android,
• IR up to 100 m,
• IP66 housing rating,
• free iVMS 4200 managing software, iVMS 4500 mobile app,
• supplying voltage: 24 VAC, PoE+.

The Hikvision DS-2DE5220I-AE K1798 speed dome camera has been equipped with high quality 2 MP (1920×1080) image sensor operating at 25 fps. The camera provides two data streams (main stream and sub-stream) and can use H.264 or MJPEG compression method. Thanks to day and night modes, the camera very well renders colors in daylight and fully makes use of its high sensitivity at night. The audio input allows for connection of a microphone, and the audio output can be connected to an active loudspeaker (with an amplifier). Such a solution enables two-way voice communication, audio monitoring of the spot, audio recording.

The P/T mechanism can change the position of the optical axis of the camera at speed of 0.1°/s…400°/s (pan) and 0.1°/s…200°/s (tilt). In conjunction with 20x optical zoom and 16x digital zoom it allows for detailed monitoring of large areas with total zoom up to 320x!. Thanks to high sensitivity, advanced processing algorithms (3D-DNR,D-WDR, Defog, HLC/BLC) and IR illuminator with range up to 150 m, the camera can effectively operate in any environment. Web access to a video stream from the camera is possible via IE, Mozilla Firefox, Opera, Google Chrome – thanks to Flash technology the image is directly displayed by the respective browser. Additionally, the camera is supplied with free iVMS 4200 software for management and control of Hikvision devices in IP networks. The mobile access to the camera via an Android smartphone is possible via free iVMS 4500 app available in Google Play.

Ezviz (EasyVision) is a free service which can be activated in Hikvision NVRs and IP cameras. This free service allows less advanced users to easily access to the video from the cameras via the Internet, without forwarding router ports. To enable remote access, the user should only connect the device to the network (which requires a valid IP address and appropriate gateway settings). The next step is the creation of user account at the www.ezviz7.com website. The account can accommodate devices in a local area network (with activated Ezviz service). The devices will be available from anywhere via the Internet.
